Lightbox 90 (curved)
Single-sided curved profile for illuminating textile prints. The backlit illumination ensures an even distribution of light. The LED is mounted on the inside of the frame. For better light reflection, a blackout fabric can be attached to the back of the frame.
Available from stock
Single-sided curved LED frame
Curved LED frames create a subtle and elegant atmosphere in a room. Through the years, these types of frames have become more and more popular. A round-shaped LED frame is immediately noticeable when you hang it or place it in a room, even if it has a calm print. The Lightbox 90 is suitable for wall-mounting and freestanding use.
Available as cylinder and curved frames
The Lightbox 90 frame is available as a cylinder and curved. The advantage of a cylinder is that it is visible from all sides. A curved frame is ideal as an impressive backdrop or partition at, for example, trade fairs. The outer groove of a Lightbox 90 open makes it easy to attach accessories. The Lightbox 90 is also available with a sleek finish, the Lightbox 90 closed. The cylinder and curved frame require a minimum radius of 2000 mm, but the bigger they are, the better they look.
LED on Stabilizer (lit from the back)
LED on stabilizers illuminates the textile print from the back with LED mounted onto stabilizers, ensuring even light distribution with sufficient power. A unique feature of the LED on Stabilizer is the choice of two light intensities and the option to dim the light. Optionally, the LED frame can be made compatible with DALI systems.
Light intensities and dimming
The LED on Stabilizer is available with two different light intensities. The Bright LED with 4,000 lumens per m² provides a bright, even light distribution. The Super Bright LED with 5,950 lumens per m² makes the textile print shine. The brightness of the LED frame is adjustable with a dimmer. This way, the light intensity can be set according to the environment. The LED dimmer is optional.
Blockout fabric for even light distribution
With a curved Lightbox 90, blockout material must be attached to the back. This ensures good light reflection. Attach the fabric with the white side facing inwards.
In every desired colour
The Lightbox 90 comes standard in silver, white and black. Do you prefer a different colour? Please enter your desired RAL colour code, and we will powder-coat the profile in the colour of your choice.
Depth MM | 90 mm |
---|---|
Frame type | Curved LED frame |
Mounting | Wall-mounted, Freestanding |
Colours | Silver, Black (RAL9005), White (RAL9016), RAL colour of your choice |
Shapes | Curved, Cylinder |
Pre-drilled | No |
Open / closed finish | Open and closed |
Weight per | 1.895 kilos/metre (open) and 1.934 kilos/metre (closed) |
LED technology | LED on Stabilizer |
Light intensity | Bright Led (4000 lumens per m2) and Super Bright Led (5950 lumens per m2) |
Light colour | 3000K, 4000K, 6500K |
Dimming | Dimmable, DALI dimmable |
Stabilizers | Yes |
Bar Length | 6150 mm |
Warranty period | Two years |
